In the sixth post of this series, we serviced the final drive of the 85G Excavator. Check out our previous post about changing the final drive oil to catch up.
In this final post, you’ll learn how to flip over the cutting edge to complete the 500-hour service interval on the 85G Excavator.
Do you prefer to see a video tutorial instead?
Need to save time? The following table shows every filter you need for the complete 500-hour service interval:
Item | OEM | Part Number | |||
---|---|---|---|---|---|
Aftermarket equivalent | |||||
Baldwin | Donaldson | Wix | Blumaq | ||
Hydraulic Return Oil Filter | 4450002 | PT9443 | N/A | N/A | N/A |
Hydraulic Breather Filter | 4437838 | PA5316 | N/A | N/A | N/A |
Engine Oil Filter | MIU800650 | B161-S | P502051 | 51568 | N/A |
Fuel Filter | MIU805005 | BF9910 | P553995 | N/A | N/A |
Water Separator Filter | MIU802421 | N/A | N/A | N/A | N/A |
Water Fuel Separator Housing + Plastic Bowl | MIA885254 | N/A | N/A | N/A | N/A |
Pilot System Oil Filter | 4630525 | N/A | N/A | N/A | N/A |
Primary Engine Air Filter | FYD00001541 | N/A | N/A | N/A | N/A |
Secondary Engine Air Filter | FYD00001327 | N/A | N/A | N/A | N/A |
Cab Fresh Air Filter | 4S00640R | N/A | N/A | N/A | N/A |
Cab Recirculating Air Filter | FYA00011003 | N/A | N/A | N/A | N/A |
Table of Content
Remove the Cutting Edge
Place the bucket on top of 2 or 3 wooden blocks to leave the cutting edge lifted.
Using an impact wrench, undo all the nuts holding the cutting edge bolts.
If you need to hold the bolts from spinning while taking out the nuts, DON’T use your hand since the bolts’ head gets razor-sharp when worn out. Instead, use a hammer or a piece of wood to keep them in place.
If you can’t take the nuts out with an impact gun, you can either torch them off or use a 20-pound sledgehammer to pop the bolts off.
Lift the bucket to separate it from the cutting edge.
With a wire wheel, clean up both faces. Make sure to wear a mask or respirator.
Reinstall the Cutting Edge
Rotate the cutting edge and place it on top of the wooden blocks.
Put the bucket down against the cutting edge, and align their holes with a crowbar/pry bar pointy end.
Screw the new nuts and bolts by hand, then tighten them with the impact gun.
Lift the bucket and run the nuts back over with the impact gun.
Smack the bucket a few times against the ground to help set the blade into its final position, and tighten the nuts one last time.
Wrapping Up
As you can see, servicing your John Deere 85G Excavator is not rocket science. However, if you don’t have the time or equipment, hire a service mechanic at Tekamo HD.
Be sure to check out the other posts we have in this series:
- Replace the Hydraulic Return Filter and the Oil Tank Breather filter.
- Change the Engine Oil and Filter.
- Replace the Engine’s Inner and Outer Air Filters.
- Replace the Fuel and Water Separator Filters.
- Change the cabin air filter.
- Change the Final Drive Oil.
